Float Bottles
The “Y” on the lowest 2 liter plastic soda bottle is the one way pneumatic fill valve….. additional valves added on off and pneumatic travel coil tube pressure dump venting valve will also be installed…. A pneumatic valve upon exit of tube from lowest bottle ( in – line flow ) and valve placed upon discharge flow tube from the middle bottle ( before ratio gear set air pump). The top bottle has in -line flow valves placed before the one way valves upon the top bottle they also to the have ability to vent the return coil tube. ( venting capacity pre- start sequence ). System composed of three, 2 liter bottles…… Inert fill gas ( Argon ) and ground shell for static electricity ( air can be used but additional electrical grounding must be installed like a electro static current pick up metal grid within the flow lines. A “start accelerator” electric “winder” to then assist in the velocity of the gear sets then by battery powered electric motor with square rotating post ( drives recess upon the gear set ) can be used to cause inertia in the ratio gear sets. Then the motors can switch to generators and charge the battery. Upon the 1:10 ratio gear set the “1” is connected to a pneumatic impeller ( rotational input ) and the “10” ( rotational output ) is then connected to an air compressor centrifugal type.
